Your best option for strong, stable, concrete formwork.

Learn more
FormPly
IPL FormPly

IPL FormPly is manufactured for use in the concrete forming industry to provide strong, stiff, lightweight support for the forming of concrete structures.

At a glance.

IPL FormPly
  • Overlaid with high quality, heavy duty phenolic resin impregnated papers to provide a hard wearing, smooth surface.
  • Superior quality and surface which transmits into the finish of the concrete.
  • Phenolic overlay paper protects the surface veneer from excessive moisture uptake which assists to minimise hydration staining and grain raising.
  • Resists dilute acids and alkalines which increases the number of uses that is obtained when used with concrete.

Usage and Maintenance

● Place long edge of sheets across the supports.
● Allow 2-3mm expansion gap on all sheet edges and if required, use some form of elastic sealer to fill the gap — the gap may have to be widened to allow for the gap filler.
● When nailing or screwing the sheets, it is essential to fix to avoid movement. When countersinking the fixings through the overlay paper it will be necessary to fill these with epoxy filler and smooth off to give good finish and limit moisture uptake.
● To avoid staining from fasteners use hot-dipped galvanised, stainless or alloy fasteners.
● Cut edges should be resealed using acrylic paint which helps keep moisture out and minimises distortion that can be caused by expansion around sheet perimeters. The factory’s cut edges are coated with a water repellent coating.
● Use release agent before use and reuse to ensure clean release from concrete and to minimise hydration staining and grain raising.
● Take care to avoid vibrator contact as much as possible to keep face intact.
● When storing sheets lay flat with support of bearers.

IPL FormPly F17 Specifications

Eucalyptus Hardwood (Imported)
Veneer
Bond
A Bond (marine bond)
Available in
2400 x 1200 x 12mm and 17mm (13ply)
Plywood Construction Standard
AS/NZ2269 – AS6669
Pack size
x54

Bending Modulus of Elasticity EN310

Longitudinal
Lateral
17mm
5985 Mpa
5010 Mpa

Bending Strength N/mm2 EN310

Longitudinal
Lateral
17mm
57 Mpa
46 Mpa

Download brochures for full details.
