Plycil
Plycil™

IPL Plycil is overlaid on both faces with a phenolic resin impregnated paper overlay providing a smooth and durable surface for painting. It’s designed for use as window reveals and sills and is a great solution for those that are 150mm or wider.

At a glance.

Plycil™
  • Manufactured from renewable plantation grown New Zealand Radiata Pine.
  • Meets NZ Building Codes according to AS/NZS 2269.
  • IPL Plycil is treated to H3.1 to withstand moisture build-up from condensation.
  • Available in the following thickness: 19mm/9ply.

Technical details.

Type
Sheet Size (mm)
Thickness (mm)
Ply
Grade
Surface
Groove Size (mm)
Groove Centres (mm)
1000/100
2440 x 1216
12
5
S
Bandsawn
6 x 8 wide
100
1000/150
2440 x 1216
12
5
S
Bandsawn
6 x 8 wide
150
1000/200
2440 x 1216
12
5
S
Bandsawn
6 x 8 wide
200
3000
2440 x 1216
12
5
S
Bandsawn
No Grooves
3000 Superior
2440 x 1216
17
5
S
Bandsawn
No Grooves

Technical Specifications

Standard – AS/NZS 2269
Wood Raw Material – Pinus Radiata
Density – average 500kg/m3
Bond – A Bond ExteriorGlue Formaldehyde Emissions E0 < 0.3mg/L(AS/NZS 2098.11).
No harmful emissions.
Preservative Treatment:
H3.1 LOSP – Light Oil Solvent Preservative treatment in accordance with AS/NZS 1604.3.

Handling and Storage:

Plywood is a natural product that can be affected by changes in ambient weather conditions, causing previously flat sheets to bow or twist. All precautions are taken to minimise this effect,however once the plywood has left our warehouse we cannot guarantee sheets to remain flat. This is particularly important where free standing kitchen/cabinet doors are concerned.

Download brochures for full details.
